Kataloge und Anleitungen zu unseren Kollektionen zum Herunterladen
Damit die Installation kein Problem ist, stellen wir Ihnen die Handbücher unserer Produkte zur Verfügung.
Anleitungen für unsere Produkte
Damit die Installation kein Hindernis darstellt, bieten wir Ihnen die Anleitungen für unsere Produkte.
- Anleitung Mutter Gewinderohr Ø32 (TCR01)
- Bedienungsanleitung Plastikschlüssel für flexiblen Schlauch
- Bedienungsanleitung für das zeitgesteuerte Solestop-Becken
- Installationsanleitung für automatische Wasserhähne von Soltronic
- Anleitung für Arola. Ref: 2601, 2601B, 2601N, SR2601N, 2610, 2610B, 2610N, SR2610N Y EG2610
- Installationsanleitung Erweiterungsset für Einbauwaschbecken
- Installationshandbuch für elektronische Wasserhähne. Art. 8130B / 8130TB
- Installationshandbuch für elektronische Wasserhähne. Art: 8121B / 8121TB
- Installationshandbuch für elektronische Wasserhähne. Art: 8120B / 8120TB
- Installationshandbuch für elektronische Wasserhähne. Art: 8119B / 8119TB
- nstallationshandbuch für elektronische Wasserhähne. Art: 8116B / 8116TB + Ref. 8118B / 8118TB
- Installationshandbuch für elektronische Wasserhähne. Art: 8115B / 8115TB
- Installationsanleitung für Einbauarmaturen mit Auslauf und Platte
- Installationsanleitung für die Außenduschsäule. Ref: COLEX01
- Installationsanleitung für einen Badewannenauslauf. Ref: CR01
- Wartungshandbuch für Wasserfallduschkopf
- Installationsanleitung für Hydrotherapie-Duschköpfe. Ref: RCRK / RCR
- Installationsanleitung für Hydrotherapie-Duschköpfe. Ref: RRK / RR
- Installationsanleitung für Hydrotherapie-Duschköpfe. Ref: RIKS
- Installationsanleitung für Hydrotherapie-Duschköpfe. Ref: RIK
- Installationsanleitung für Hydrotherapie-Duschköpfe. Ref: RIR
- Installationsanleitung für Hydrotherapie-Duschköpfe. Ref: RCE02
- Installationsanleitung Hydrotherapie-Duschkopf für Waschbecken. Nr.: 169
- Installationsanleitung für Hydrotherapie-Duschköpfe. Ref: RC / RCEXT
- Installationsanleitung für Hydrotherapie-Deckenduschen mit Vernebler
- Installationsanleitung für Unterputz-Duschkopf
- Installationsanleitung für die Duschsäule. Ref: T100N + IDH1/2 + SFT19U
- Installationsanleitung für Badewannen-Duschsäule. Art.-Nr.: DN130D + T18 + IDP16
- Maintenance Manual for shower column. Ref: T100D
- Maintenance Manual for shower column. Ref: T20003RP200
- Maintenance Manual for shower column
- Maintenance Manual for shower column. Ref: DN130
- Installation Manual Shower Column. Ref: T100N + RGD
- Installation Manual Shower Column. Ref: T100N + IDH1/2
- Installation Manual Shower Column. Ref: DN130 + IDH 1/2
- Installation Manual Shower Column. Ref: T100N
- Installation Manual Shower Column. Ref: DN130 + IDI + RGD
- Installation Manual Shower Column. Ref: DN 130 D
- Installation Manual bath and shower column. Ref: 9356/9456
- Installationsanleitung für Waschtisch-, Dusch- und Badewannenarmaturen
- Installationsanleitung für Waschtisch-, Dusch- und Badewannenarmaturen
- Installationsanleitung für Thermostatarmaturen
- Installationsanleitung für Küchenarmaturen Pure Water. Ref: 3889
- Installationsanleitung für Küchenarmaturen. Nr.: 3829 / 3886
- Installationsanleitung für Küchenarmaturen. Ref: 331902H1/931902H1 641901H1/661901H1/751901H1/337902V1/937902V1 647901V1/667901V1/757901V1/331902H2/931902H2 641901H2/661901H2/751901H2/33902V2/937902V2 647901V2/667901V2/757901V2
Videos über Ramonsoler-Produkte
Die neuesten Armaturen, Kollektionen, Anleitungen und Tipps.
Ramon Soler® | Von Barcelona in die ganze Welt
Entdecken Sie, wer wir sind, was wir tun und wie wir es von unserem Hauptsitz in Barcelona aus in die ganze Welt tun.
Brand Stories: Once upon a time...Ramon Soler® | OCTOBER
Delve into the history of Ramon Soler®, faucet creators since 1890, told by Jordi Soler Fornt (CEO), at the company's Flagship Store in Barcelona.
Ramon Soler®'s Flagship Store in Barcelona
Report made by Thereports.tv about the Ramon Soler's Flagship Store in Barcelona and the recent IF DESIGN AWARD 2020 for the Urban Chic collection.
Wie installiere ich einen zeitgesteuerten Wasserhahn? Regulierung von Zeit und Fluss. | alleinige Haltestelle
Installationsvideo-Tutorial für das QUICK SET-UP-System und 4 SAVING POSITIONS, ein Durchfluss- und Zeitoptimierungssystem, das um bis zu 85 % reduziert werden kann.
Wie installiere ich einen eingebauten Mixer?
Visuelle Installationsanleitung für einen Einhebel-Einbaumischer mit exklusivem ästhetischem Design, einer 2 mm dicken Platte und ohne sichtbare Befestigung.
Wie installiere ich eine 1-Wege-Verlängerung für einen eingebauten Mixer?
Die visuelle Bedienungsanleitung zur optimalen Installation unserer Einbau-Einhebelmischer, mit 1-, 2- und 3-Wege-Verlängerungen.
How to install a single lever concealed 2 and 3 ways extension kit?
Die visuelle Bedienungsanleitung zur optimalen Installation unserer Einbau-Einhebelmischer, mit 2-Wege- und 3-Wege-Verlängerung.
Wie installiere ich einen eingebauten Thermostat?
Visuelle Installationsanleitung für einen Thermostat-Einbaumischer mit exklusivem ästhetischem Design, einer 2 mm dicken Platte und ohne sichtbare Befestigung.
Wie installiere ich eine 1- und 2-Wege-Verlängerung für eingebaute Thermostate?
Die visuelle Anleitung zur optimalen Installation unserer Einbau-Thermostate mit Erweiterung auf bis zu zwei Möglichkeiten.
Wie kann man die maximale Temperatur einer Mischbatterie begrenzen?
System, das die Höchsttemperatur des Warmwassers begrenzt und so die Gefahr von Verbrennungen sowie übermäßigen Warmwasserverbrauch vermeidet.
How to install a bathroom faucet?"
Video-Tutorial zur Installation einer Einhebel-Waschtischarmatur, damit der Vorgang reibungslos verläuft und das Ergebnis wirklich makellos ist.
So installieren Sie eine Duschsäule ohne Wechselrichter und feste Säule.
Video-Tutorial zur Installation einer Duscharmatur ohne manuellen Umsteller, egal ob fest oder teleskopisch.
So installieren Sie eine Duschsäule ohne Wechselrichter und Teleskopsäule.
Video-Tutorial zur Installation einer Duscharmatur ohne manuellen Umsteller in Teleskop-Ausführung.
So installieren Sie eine Duschsäule mit Wechselrichter und fester Säule
Installation von Einhebel-Duschsäulen mit Umstellung und fester Stange, um ein komplettes Badezimmer mit zwei verschiedenen Strahlarten, Kopfbrause und Handbrause zu genießen.
So installieren Sie eine Duschsäule mit Wechselrichter und Teleskopsäule
Installation von Einhebel-Duschsäulen mit Umsteller und Teleskopstange, um ein komplettes Badezimmer mit zwei unterschiedlichen Strahlwegen, Kopfbrause und Handbrause zu genießen.
So installieren Sie eine Säule für eine Badewanne mit Dusche
Installation von Badezimmer-Duscharmaturen, eine Komplettlösung, die es uns ermöglicht, eine Badewanne auszustatten und den Duschkopf und die Handbrause zu behalten.
Urban Chic von Ramon Soler® IF DESIGN AWARD 2020
Eine Kollektion, die unsere menschlichsten Wünsche, die Natur zu genießen, mit unserem urbanen Lebensraum verbindet.
Wc Magnet by Ramon Soler®
Komfort und Sicherheit im WC mit dieser intelligenten Innovation, einem Einhebelmischer mit doppeltem Absperrventil dank patentiertem Magnetsystem.
Ramon Soler® C2/S2 Wassersparsystem
Wasser sparen ist mit unseren Wasserhähnen und ihrem gestaffelten Öffnungssystem oder in zwei Phasen C2/S2 möglich.
C2/23 Energy and Water Saving System by Ramon Soler®
Wir sparen nicht nur Wasser, sondern kümmern uns auch um den Energieverbrauch mit unserem C3/S3-Kaltöffnungssystem, der Kombination beider Ressourcen in einem System.
Die neuesten Küchenarmaturen, Magnet Collection von Ramon Soler®
Trends in der Küche zu setzen, ist mit der Armatur mit ihrer avantgardistischen Ästhetik, den reinen Linien und organischen Formen möglich, die in ein Satin-Kupfer-Finish gekleidet sind, das nicht unbemerkt bleibt.
Werkzeugfreie Wasserhähne aus Titan | Schnelle und einfache Installation ohne Werkzeug
Die funktionale Minimalismus-Kollektion präsentiert 2022 eine Änderung im Design ihrer Waschtischarmatur und Verbesserungen im Befestigungssystem.
Adagio by Ramon Soler®
Design between art and science. A combination of geometric shapes that have a mathematical order, limited by straight lines and curves, with organic shapes.
Wartungshinweise für unsere Wasserhähne
Tipps zur Pflege Ihrer Wasserhähne, die Ihnen helfen, sie stets im besten Zustand zu halten.
Verwenden Sie PH-neutrale Seife.
Nach Benutzung des Wasserhahns mit einem weichen Tuch abwischen, um Kalkablagerungen zu vermeiden.
Mit ausreichend Wasser abspülen, um alle Reinigungsmittelreste zu entfernen.
Trocknen Sie den Wasserhahn mit einem weichen Tuch.
Für die ordnungsgemäße Wartung von Sprinklern und Handbrausen ist es wichtig, die Silikondüsen regelmäßig zu reinigen, indem Sie mit den Fingern über die Düsen streichen, damit sich Kalkablagerungen lösen.
Ramon Soler übernimmt keine Garantie, wenn Sie diese Reinigungs- und Wartungsempfehlungen nicht befolgen.
Verwenden Sie keine Reinigungsmittel, die Säuren (Salz-, Ameisen-, Phosphor- oder Essigsäure), Alkohol, Antikalk oder ähnliches enthalten.
Mischen Sie nicht verschiedene Reinigungsmittel.
Benutzen Sie keine Verdampfer.
Verwenden Sie keine scheuernden Produkte wie Schwämme.
Verwenden Sie das Reinigungsmittel nicht direkt auf dem Wasserhahn, sondern mit einem weichen Tuch.
Wir klären die häufigsten Fragen
Installations-, Reinigungs- und Wartungstipps und mehr!
Single lever
Two handle mixer
Thermostatic
Column
Kitchen
Electronic / Contactless
Timed
Hydrotherapy
Spare parts
The nut is loose / Solution: tighten the nut on your single lever
The cartridge is broken down / Solution: Change the cartridge
Single lever with aerator
-The aerator is clogged / Solution: Change or clean the aerator.
-The flexible hose is clogged or crooked / Solution: Change or clean the flexible hose.
-Cast iron defect (only in the case of newly installed taps) / Contact technical service, the tap must be replaced.
o Single lever with waterfall output.
- The flexible hose is clogged or crooked / Solution: Change or clean the flexible hose
Filters are clogged / Solution: Change or clean filters with vinegar.
-The flow limiter is clogged / Solution: Change or clean the flow limiter.
-Cast iron defect (only in the case of newly installed taps) / Contact technical service, the tap must be replaced.
The nut is loose / Solution: Tighten the nut on your single lever
The cartridge is damaged / Solution: Change the cartridge
The rubber seals are broken / Solution: Replace the rubber seals
The hose is broken / Solution: Change the hose
Answer 5 monomando
The boiler does not have enough power / Solution: Install a shower handle with less flow or insert a flow limiting seal.
Single lever wall mounted
-The pressure is insufficient / Solution: check the installation and increase the pressure to 1 bar, Otherwise it is possible to pull and turn the diverter half turn to lock position.
Single lever concealed
- The pressure is insufficient / Solution: check the installation and increase the pressure to 1 bar.
- The shaft is dirty / Solution: disassemble the diverter, clean and grease the shaft.
- Spring has lost load / Solution: disassemble the diverter. If it does not maintain shower position, stretch the large spring 2—3 mm.
The diverter has dirt particles or is broken / Solution: disassemble the diverter and clean the rubber seals or replace the diverter.
The rubber seal is deformed / Solution: Loosen the handle and reposition the rubber seal or replace it with a new one. If that doesn't work, try putting two of it.
It drips constantly (more than an hour). It may happen that:
-The nut is loose / Solution: tighten the nut on your single lever
-The cartridge is damaged / Solution: Change the cartridge
It drips a few minutes
-The capillary of the nozzles is dirty with adhering lime. (It is not a breakdown) it is water accumulated in the showerhead. / Solution: Clean the showerhead nozzles. If you want, you can slightly tilt the showerhead to facilitate faster drainage.
It drips constantly (more than an hour). It may happen that:
-The nut is loose / Solution: tighten the nut on your single lever
-The cartridge is damaged / Solution: Change the cartridge
o it drips a few minutes
o The capillary of the nozzles is dirty with adhering lime. (It is not a breakdown, it is accumulated water .) / Solution: Clean the nozzles. If you want, you can slightly tilt the handle to facilitate faster drainage.
Ceramic frame is damaged / Solution: Change or clean the ceramic frame. (To identify a damaged frame, close one of the cold or hot water intakes and if it stops dripping, identify the frame)
Conventional frame damaged / Solution: Clean tap seat or replace frame. (To identify a damaged frame, close one of the hot or cold water intakes and if it stops dripping, identify the frame)
The aerator is clogged / Solution: Change or clean the aerator.
The flexible hose is clogged or crooked / Solution: Change or clean the flexible hose.
Cast iron defect (only in the case of a newly installed tap) / Contact technical service, the tap must be replaced.
The frame is loose / Solution: Tighten the frame .
The frame is broken / Solution: Change the frame
The rubber seals are broken / Solution: Replace the seals.
The hose is broken / Solution: Change the hose
The hose is loose / Solution: Tighten the hose
Damaged hose / Solution: Change the hose (Evaluate if the spout has been deformed, in that case, change the spout as well)
The boiler does not have enough power / Solution: Install a showerhead with less flow or insert a flow limiting seal.
Single lever wall mounted:
- The pressure is insufficient / Solution: check the installation and increase the pressure to 1 bar, otherwise it is possible to pull and turn the diverter half turn to lock position.
o Single lever concealed:
- The pressure is insufficient / Solution: check the installation and increase the pressure to 1 bar.
- The shaft is dirty / Solution: disassemble the diverter, clean and grease the shaft.
- Spring has lost load / Solution: disassemble the diverter, if it does not maintain shower position, stretch the large spring 2—3 mm.
The diverter has dirt particles or is broken / Solution: disassemble the diverter and clean the rubber seals or replace the diverter.
The rubber seal is deformed / Solution: Loosen the handle and reposition the rubber seal or replace it with a new one. If that doesn't work, try putting two of it.
It drips constantly (more than an hour). It may happen that:
- Frame damaged / Solution: Change or clean the frame.
It drips a few minutes
-The capillary of the nozzles is dirty with adhering lime. (It is not a breakdown, it is water accumulated in the showerhead ) / Solution: Clean the showerhead nozzles. If you want, you can slightly tilt the showerhead to facilitate faster drainage.
It drips constantly (more than an hour). It may happen that:
- Frame damaged / Solution: Change or clean the frame.
It drips a few minutes
- The capillary of the nozzles is dirty with adhering lime. (It is not a breakdown, it is accumulated water that comes out.) / Solution: Clean the nozzles. If you want, you can slightly tilt the handle to facilitate faster drainage.
The nut is loose / Solution: tighten the nut on your single lever.
The closing mechanism is broken down/ Solution: Change the mechanism (cartridge /frame)
The filters are clogged/ Solution: Clean the filters with vinegar.
Cast iron defect (only in the case of a newly installed tap) / Contact technical service, the tap must be replaced.
Lack of pressure in the installation or decompensated pressure. / Solution: Check that the pressure is between 1-5 bar (Recommended pressure 3 bar) and compensated.
Handle flow/diverter -The mechanism is broken down / Solution: Change or clean the mechanism.
Handle flow/diverter nut is loose. / Solution: tighten the nut on your ceramic diverter or ceramic frame.
Temperature handle The thermostatic cartridge is broken down / Solution: Clean or change the rubber seal.
Change the thermostatic cartridge, clean and rinse the internal surface of the tap, and grease the seal
The hot and cold water inlets are reversed / Solution: Verify in the installation that the hot water enters from the left of the thermostatic, if not, you must contact the installer.
The thermostatic tap has not been assembled backwards. (The hot water intake is marked) / Solution: Turn on the tap or check if there is an alternative available.
The thermostatic cartridge has stopped regulating due to disuse, impurities or lime build-up. / Solution: Disassemble and clean the cartridge. If it is not possible to recover, change the cartridge.
Dirt in filters / Solution: Clean the filters located in the water inlets.
Cold water dominates hot water. / Solution: Check in the intakes that the pressure is between 1 - 5 bar (Recommended pressure 3 bar) and compensated.
The hot water temperature is very high. / Solution: Set the maximum temperature of the hot water in the boiler between 50º -60ºC
Dirt in filters / Solution: Clean the filters located in the water inlets
The water service conditions have been modified ( pressure and / or temperature). Solution: Adjust the comfort temperature again, according to the instructions for adjusting the cartridge
The thermostatic cartridge is blocked. / Solution: disassemble and clean the cartridge. If it is not possible to recover, change the cartridge.
The temperature limiter ring has been moved of its place. / Solution: disassemble the cross head and the ring. If it is broken replace the ring.
Cold water dominates hot water. / Solution: Check in the intakes that the pressure is between 1 - 5 bar (Recommended pressure 3 bar)
The boiler is regulated for a water demand greater than the flow required by the shower handle. / Solution: Adjust the boiler.
The boiler does not have enough power (See requirements in the instructions). Check: lower the flow rate to 50% or less and wait a few minutes. / Solution: Adapt the installation. As an alternative you can improve the functionality if you install a showerhead with less flow or insert a flow limiting seal
The cold water non-return valve (right side) is blocked. / Solution: Disassemble the non-return valves for cleaning. Replace if necessary.
The hot water non-return valve (left side) is blocked. / Solution: Remove the non-return valves for cleaning. Replace if necessary.
Blocked non-return valve / Solution: Clean the non-return valves and check that they move freely or replace the non-return valve.
The pressures of the water intakes are very high. / Solution: Check in the intakes that the pressure is between 1-5 bar (Recommended pressure 3 bar)
Installation of the pipes is not correct and causes turbulence or vibration. / Solution: Check the installation.
o High hot water temperature> 65º. / Solution: Check the supply temperature and regulate the temperature in the range 50ºC-60ºC.
There is something that generates turbulence inside the tap. / Solution: Check that there are no remains of construction material in the tap. Otherwise, contact technical service, the tap must be replaced.
The diverter has dirt particles or is broken / Solution: Disassemble the diverter and clean the rubber seals or replace the diverter.
The rubber seal is deformed / Solution: Loosen the handle and reposition the rubber seal or replace it with a new one. If that doesn't work, try putting two of it.
It drips constantly (more than an hour). It may happen that:
- Frame damaged / Solution: Change or clean the frame.
It drips a few minutes
- The capillary of the nozzles is dirty with adhering lime. (It is not a breakdown, it is accumulated water in the shower head.) / Solution: Clean the shower head nozzles. If you want, you can slightly tilt the shower head to facilitate faster drainage.
It drips constantly (more than an hour). It may happen that:
- Frame damaged / Solution: Change or clean the frame.
o It drips a few minutes
- The capillary of the nozzles is dirty with adhering lime. (It is not a breakdown, it is accumulated water.) / Solution: Clean the nozzles. If you want, you can slightly tilt the handle to facilitate faster drainage.
Your installation does not meet the foreseeable standard. / Solution: Acquire the column fixation kit that contains different measures for its adaptation.
The eccentrics are not well aligned. / Solution: Correct the position of the eccentrics.
The dimensions of the column have not been taken into account with regard to the installation. / Solution: Purchase the telescopic bar, adaptable to a wide range of measurements.
The boiler does not have enough power (See requirements in the instructions). Check: lower the flow rate to 50% or less and wait a few minutes. Solution: Adapt the installation. As an alternative you can improve the functionality if you install a shower head with less flow or insert a flow limiting seal.
The diverter has dirt particles or is broken / Solution: Remove the diverter and clean the rubber seals or replace the diverter.
The rubber sealing is deformed / Solution: Release the handle and reposition the seal or replace it with a new one. If that doesn't work, try putting two of it
It drips constantly (more than an hour). It may happen that:
- Breakdown closing element / Solution: Change or clean the element.
o It drips a few minutes
- The capillary of the nozzles is dirty with adhering lime. (It is not a breakdown, it is water accumulated in the shower head.) / Solution: Clean the shower head nozzles. If you want, you can slightly tilt the shower head to facilitate faster drainage. It is not a breakdown
It drips constantly (more than an hour). It may happen that:
Breakdown closing element / Solution: Change or clean the element.
It drips a few minutes:
- The capillary of the nozzles is dirty with adhering lime. (It is not a bdreakdown, it is accumulated water that comes out.) / Solution: Clean the nozzles. If you want, you can slightly tilt the handle to facilitate faster drainage. It is not a breakdown
It has been overtightened. / Solution: Loosen, reposition the rubber seal by tightening it, and check that it has not been damaged. Replace if necessary.
The rubber seal is displaced. Solution: Loosen and reposition the rubber seal by tightening it.
The seat of the bar and / or diverter are damaged / Solution: Replace damaged parts.
The nut is loose / Solution: tighten the nut on your single lever
The cartridge is damaged / Solution: Change the cartridge
Single lever with aerator
- The aerator is clogged / Solution: Change or clean the aerator.
- The flexible hose is clogged / Solution: Change or clean the hoses.
- Cast iron defect (only in the case of newly installed taps) / Contact technical service, the tap must be replaced.
The nut is loose / Solution: Tighten the nut on your single lever.
The cartridge is defective / Solution: Change the cartridge
The rubber seals are broken / Solution: Replace the rubber seals.
The hose is broken / Solution: Change the hose.
The hose is loose / Solution: Tighten the hose
Damaged hose/ Solution: Change the hose. (Evaluate if the spout has been deformed, in this case, also change the spout)
The shower does not change between the two functions / Solution: Change the shower.
The extensible hose does not come out. It is blocked / Solution: Check that it is correctly installed and that there is nothing to interfere with the movement.
The extensible hose does not fit. It does not recover the position / Solution: Check that it is correctly installed and that there is nothing to interfere with the movement. Check that the weight is free of movement.
Leak enters in the union of the extensible hose and the tap / Solution: Check that it is tight.. If not, replace the rubber seal or the flexible hose.
Low flow: the membrane electrovalve is dirty and / or damaged. / Solution: Disassemble for cleaning. Replace if necessary.
Normal flow: The electrovalve is blocked. / Solution: Remove the electrovalve and unlock the shaft. Replace if necessary.
The red light on the sensor flashes constantly when the user's hands are near the sensor.
Weak battery. / Solution: replace the battery.
The red light on the sensor does not flashes when the user's hands are near the sensor.
Inadequate stopping range. / Solution: Adjust the detection range.
- Dead battery or no electrical connection / Solution: Check the connection. Replace the battery.
- The unit is in “Security Mode” (if the sensor is active for a long time, the tap automatically closes the water) / Solution: Check that there is no obstacle or dirt on the sensor. If so, remove it to exit security mode.
- The sensor is picking up reflections from a shiny object . / Solution: Eliminate the cause of the reflection.
The red light on the sensor flashes once when the user's hands are near the sensor.
- The electro valve is blocked. / Solution: disassemble the electrovalve and unlock the shaft. Replace if necessary.
- The central hole in the membrane is damaged. / Solution: Disassemble for cleaning. Replace if necessary.
- The pressure is high (> 8 bar) or has suffered a specific pressure rise. / Solution: Reduce supply pressure. If the problem persists, purge the tap to eliminate residual pressure. (press the non-return valve of the flexible hose)
Filters are clogged. / Solution: Change or clean the filters.
The aerator is clogged / Solution: Change or clean the aerator.
The flexible hose is clogged/ Solution: Change or clean the hoses.
Defect of cast iron (only in case of newly installed faucet) / Contact technical service, the faucet must be replaced.
Inadequate flow regulation / Solution: Adjust the flow regulation according to the instructions.
The aerator is clogged / Solution: Change or clean the aerator.
The flexible hose is clogged / Solution: Change or clean the hoses.
Defect of cast iron (only in case of newly installed faucet) / Contact technical service, the faucet must be replaced.
The cartridge is broken / Solution: Change the cartridge.
Dirt in the cartridge / Solution: Clean the cartridge. Follow the faucet maintenance instructions.
Inadequate regulation / Solution: Adjust the time regulation according to the instructions.
Dirty or deteriorated cartridge / Solution: Clean the cartridge. Follow the faucet maintenance instructions. Replace if necessary.
The nozzles are dirty (lime build-up). / Solution: With the equipment on, run your finger over the silicone nozzles to remove the lime and / or immerse it in vinegar for 24 hours and rinse with water.
Some nozzles are broken. / Solution: Replace the nozzles. Check available models.
The flow limiter is clogged/ Solution: Disassemble for cleaning. Replace if necessary.
The waterfall is dirty. / Solution: Clean with the special key provided.
The flow of water has been reduced / Solution: Consult the question about abnormally low flow, in the corresponding tap model.
The nebulizer is clogged / Solution: Disassemble for cleaning. If necessary replace
The rubber seal is deformed / Solution: Loosen the handle and reposition the rubber seal or replace it with a new one. If that doesn't work, try putting two of it.
It drips constantly (more than an hour). It may happen that:
- Breakdown closing element / Solution: Change or clean the element.
It drips a few minutes:
- The capillary of the nozzles is dirty with adhering lime. (It is not a breakdown, it is water accumulated in the shower head.) / Solution: Clean the shower head nozzles. If you want, you can slightly tilt the showerhead to facilitate faster drainage. It is not a breakdown
It drips constantly (more than an hour). It may happen that:
- Breakdown closing element / Solution: Change or clean the element.
It drips a few minutes:
-The capillary of the nozzles is dirty with adhering lime. (It is not a breakdown, it is accumulated water.) / Solution: Clean the nozzles.
If your tap is currently in the catalog:
- See the reference on the web. Spare parts lists are available there.
If your tap is old or you do not know the reference, contact us at info@rsramonsoler.com
Ramonsoler-Projekte weltweit
Entdecke die verschiedenen Armaturenprojekte, die wir durchgeführt haben.
Hotel Ushuaia Tower
Ibiza, España
Hotel Hilton
Bora Bora, Thaiti
Nadia Bathroom Project
Moscow, Russia
Stade des Lumières
Lyon, France
Maison Paramount Tower 3
Dubai, UAE
Vertigo Lounge Luxury Restaurant Hornchurch
London, United Kingdom
Mercat Princesa Restaurant
Barcelona, Spain
Queen Mary II
St. Nazaire, France
Wine Cellar González Byass Tío Pepe
Jerez de la Frontera, Spain.
Mövenpick
Dubai, UAE
Square Business Bay
Dubai, UAE
Grand Palladium White Island Resort & Spa
Ibiza, Spain
Almasa Towers
El Alamein, Egypt
C Central Resort the Palm Jumeirah 5*
Dubai, UAE
Private House by Sena Interior Design
Warschaw, Poland
Gran Via Marina Complex
Constanta, Romania
Marriot los sueños
Costa Rica, Mexico
Gardenia 257 Townhomes Villas
Dubai, UAE
Rezidential Orhideelor 4
Chiajna, Romania
Lacul Morii Residential
Bucharest, Romania
Splaiul Independentei Residential Complex
Bucharest, Romania
Benicàssim Apartments
Comunidad Valenciana, Spain
Lyon Cité Internationale
Lyon, France
Doña Elsie
Santa Ana (San José), Costa Rica
Natura Viva Residences
San José, Costa Rica
Elite Towers Residence
Dubai, UAE
Business Bay Executive Towers
Dubai, UAE
Shorooq & Ghoroob Mirdif
Dubai, UAE
Jumeirah Park Villas
Dubai, UAE
Arabella Townhouses in Mudon
Dubai, UAE
Red Residence
Dubai, UAE
Dubailand Residential Tower
Dubai, UAE
PPP Projects at Al Madina Al Shamalia
Bahrain, Middle East
Al Ramli Housing Projects (1265 u.)
Salmabad, Bahrain
Deerat Al Oyoun (Mazaya) Diyar Al Muharraq
Bahrain, Middle East
ASGC TOWER Dubailand
Dubai, UAE
Serena Project by Dubai Properties
Dubai, UAE
Vida Residence, Downtown Dubai by Emaar
Dubai, UAE
Beccar Plaza
Buenos Aires, Argentina
Quartier Nordelta
Nordelta, Argentina
Olivos Eco Residential
Buenos Aires, Argentina
Ciudad Ribera Residential
Rosario (Santa Fe), Argentina
Lumiere Palermo Residential
Buenos Aires, Argentina
Wave Libertador Residential
Olivos (Buenos Aires), Argentina
Vila Vela Residential
Nuevo Delta (Tigre), Argentina
Liberty Belgrano Residential
Buenos Aires, Argentina
Villa Angela
Posadas, Argentine
Ribera Nordelta
Nordelta, Argentina
Lux Tower
Punta del Este, Uruguay
Torres Barcelona Residential
Punta del Este, Uruguay
Lunas de Malvin Residential
Montevideo, Uruguay
Terra Viva Bosque Real
Ciudad de Mexico, Mexico
Novogar
Heredia, Costa Rica
Salinas de Mar Residential
Viña del Mar, Chile
Luis Bascuñan Residential
La Dehesa, Chille
Phorma Building
Lima, Peru
Kirebe Project
Santa Ana (San José), Costa Rica
8 Private Villas by Saleh Al Kameshki
Manama, Bahrain
Estiba Twer - 22 storey building
Bahrain, Middle East
Weston Tower - 15 Storey Building
Bahrain, Middle East
Al-Ula Housing by Ministry of Housing
Al-Ula, Saudi Arabia
Tayma, Saudi Arabia
Bloom Towers
Dubai, UAE
Merano Tower
Dubai, UAE
Mudon CASA VIVA Fase 3
Dubai, UAE
Serena Community Centre
Dubai, UAE
Cuatrecasas Headquarters
Barcelona, Spain
Nestle Spain
Barcelona, Spain
Diagonal 640 Building
Barcelona, Spain
Bawabat Alsharq Mall
Abu Dhabi, UAE
Daleel Petroleum Headquarters
Muscat, Oman
City Center Mall
Ajman, UAB
Dalma Mall
Abu Dhabi, UAE
Standard Chartered Bank Tower
Dubai, UAE
National Bank of Fujairah
Fujairah, UAE
Porsche and Audi Showrooms
UAE
Warehouse & Showroom Suhail Bahwan Group
Muscat, Oman
Seef Mall West Expansion
Seef District (Manama), Bahrain
Manateq Zona Franca Headquarters
Doha, Qatar
Dubai South Mall
Dubai, UAE
Waldorf Astoria
Dubai, UAE
Hard Rock Cafe
Ibiza, España
Hotel 2122
Punta del Este
Golden Tulip Carthage Hotel
Carthage, Tunisia
Novum by the Sea
Olimp, Romania
Hard Rock Hotel
Ibiza, Spain
Waldorf Astoria (Habtoor Island Resort & Spa)
The Palm Jumeirah, Dubai, UAE
Tahiti Nui
Tahiti, French Polynesia
Manava Beach Resort & Spa Moorea
Tahiti, French Polynesia
Bora Bora Hilton
Tahiti, French Polynesia
Hotel Kia Ora Resort & Spa
Tahiti, French Polynesia
Intercontinental Bora Bora
Papua, Indonesia
Sofitel Kia Ora Moorea Beach Resort
Tahiti, French Polynesia
Legends Resort Moorea
Tahiti, French Polynesia
Hilton Alexandria Hotel
Alexandria, Egypt
The Cove Rotana Resort
Ras Al Khaimah, UAE
Brisas Galeria Plaza Irapuato Hotel
Irapuato, Mexico
Montarto Hotel
Baqueira-Beret (Vall d Aran), Spain
Ushuaïa Ibiza Beach Hotel
Ibiza, Spain
Broquetas Spa
Caldes de Montbui (Barcelona), Spain
Alba Seleqtta Hotel
Lloret de Mar (Girona), Spain
Soho House Garraf
Garraf (Barcelona), Spain
Gran Palladium Costa Mujeres
Riviera Maya, Mexico
Golden Bahia de Tossa Hotel & SPA
Tossa de Mar, (Girona), Spain
Golden Port Salou Hotel & SPA
Salou, (Tarragona), España
Golden Donaire Beach Hotel
Salou (Tarragona), España
Gran Medinaceli Hotel
Barcelona, Spain
Pedro I de Aragón Hotel
Huesca, Spain
Albarracín Hotel
Teruel, Spain
Room Mate Hotels Emma
Barcelona, Spain
Colonial Hotel
Barcelona, Spain
Sheraton Airport Hotel & Conference Center
Frankfurt, Germany
B&B Hotels France
France
Hôtel l’Adresse
Paris, France
Hotel del Mar
Barcelona, Spain
Hotel Ciutadella
Barcelona, Spain
Sidorme Hotel
Viladecans (Barcelona), Spain
Vincci Hotel Malaga
Malaga (Andalusia), Spain
Ilunion Barcelona Hotel
Barcelona, Spain
Candido Hotel (Hotusa Segovia)
Segovia, Spain
El Palace Barcelona Hotel
Barcelona, Spain
Hilton Cairo Hotel
Cairo, Egypt
Abadía de los Templarios Hotel
La Alberca (Salamanca), Spain
Mediterraneo Park Hotel
Roses (Girona), Spain
Linsberg Asia Hotel & Spa
Bad Erlach, Austria
Medium Prisma Hotel
Barcelona, Spain
Virgen de los Reyes Hotel
Seville (Andalusia), Spain
Ramada Hotel
Dubai, UAE
Dhow Palace Hotel
Dubai, UAE
Arjaan Rotana Hotel, Media City
Dubai, UAE
Albatros Hotel
Usuhaia, Argentina
Atlantico Hotel
Punta del Este, Uruguay
2122 Hotel Art Design
Punta del Este, Uruguay
Costa Colonia Hotel
Colonia del Sacramento, Uruguay
Real Colonia Hotel & Suites
Colonia del Sacramento, Uruguay
Radissun Blu
Heliopolis (Cairo), Egypt
Hotel See Park Janseen
Geldern, Germany
Kubb Sevilla Hotel
Seville (Andalusia), Spain
Aleu Universitary Residence
Barcelona, Spain
School Wadi Kabir
Muscat, Oman
Lycée Hôtelier
Paris, France
Merica Student Residence
Merida, Spain
Al Ghurair University
Dubai, UAE
Al Diyafah International School
Abu Dhabi, UAE
Girona Medical Clinic
Girona, Spain
Corniche Hospital Extension
Abu Dhabi, UAE
Naid Al Hamar Health Centre
Dubai, UAE
Al Mizhar Health Centre
Dubai, UAE
Algarve Hospital
Algarve, Portugal
Quiron Hospital
Marbella (Andalusia), Spain
Ministry of Housing at several locations
Bahrain, Middle East
Jerez Airport
Jerez de la Frontera, Spain.
Assembly of Extremadura
Mérida (Extremadura), Spain
Oman Cricket Academy
Muscat, Oman
Palau de la Generalitat de Catalunya
Barcelona, Spain
Police Headquarters
Dubai, UAE
Masdar Headquarters
Abu Dhabi, UAE
Civil Aviation HQ Building
Muscat, Oman
Sultan Qaboos Youth Complex for Culture and Recreation
Salalah, Oman
Baushar Stadium
Salalah, Oman
Sultan Qaboos Mosque
Jalan Oman,
Public Prosecutor’s Office
Abu Dhabi, UAE
Neuigkeiten und Kataloge
Die neuesten Nachrichten über Ramonsoler, neue Kataloge und Produkte.
Prisma gana el premio Red Dot Design Award 2024
Nuestra nueva colección de griferías Prisma recibe un reconocimiento internacional al diseño y la innovación por sus monomandos de lavabo.
Mehr lesen
Éxito de ramonsoler y solerbath en el Salone del Mobile.Milano 2024
Desde el 16 hasta el 21 de abril, estuvimos presentes en la 62ª edición del Salone del Mobile.Milano 2024 en el recinto Rho Fiera Milano, Italia. Una de las ferias de referencia mundial para el sector mobiliario y el diseño, que reúne las empresas más innovadoras para compartir sus últimas creaciones
Mehr lesen
Gran exhibición de ramonsoler en CEVISAMA 2024
Desde el pasado 26 de febrero hasta el 1 de marzo, ramonsoler tuvo la oportunidadb de participar en la última edición de CEVISAMA, en la feria de Valencia.
Mehr lesen
Ramon Soler Group presenta el nuevo catàlogo de solerbath
Ramon Soler Group anuncia el lanzamiento de su catálogo solerbath, una nueva firma de sanitarios y lavabos que redefine la experiencia en el diseño y funcionalidad en el baño.
Mehr lesen
ramonsoler® galardonado con el premio German Design Award 2024
ramonsoler® galardonado con el premio German Design Award 2024 por su nuevo re- branding "El Arte de Fluir"
Mehr lesen
Rebuild 2023
Ramon Soler® presenta sus novedades más sostenibles en la feria Rebuild 2023, en IFEMA Madrid
Mehr lesen
Blautherm de Ramon Soler®
Columnas termostáticas Blautherm de Ramon Soler, ahora con rociador cuadrado XXL ultraslim
Mehr lesen
Civic de Ramon Soler®
Ramon Soler® lanza la colección Civic, una nueva línea de grifos para baño y cocina ‘todoterreno’
Mehr lesen
Premio CEO del Año a Jordi Soler Fornt
Un reconocimiento a su labor en la dirección de la industria empresarial en España.
Mehr lesen
Adagietto de Ramon Soler®
Adagio expresa su aire más minimalista y simétrico con su versión Adagietto
Mehr lesen
Reconocimientos internacionales
Fruto del compromiso con el diseño, la innovación y el detalle
Mehr lesen
Baño Adagio de Ramon Soler®
Creatividad y elegancia en el baño, con la nueva grifería Adagio.
Mehr lesen
Baño Slow life de Ramon Soler®
Con la nueva gama de accesorios Ergos y la colección Adagio.
Mehr lesen
Pure Water de Ramon Soler®
Extraíble, con sistema de imanes y con sistema de filtrado de agua incorporado.
Mehr lesen
Ramon Soler® experto en griferías para Hoteles
Perfecciona sus griferías y sistemas de ducha...
Mehr lesen
Urban Chic abandera el diseño y la innovación
La grifería galardonada con el German Design...
Mehr lesen
Ramon Soler® lanza el nuevo Catálogo-Tarifa 2022
Todos los detalles sobre más de 2.000 referencias...
Mehr lesen
Proyecto Baño Polonia de Ramon Soler
Un baño majestuoso con la grifería Kuatro de líneas rectas...
Mehr lesen
Urban Chic se rinde a los acabados en color
La galardonada colección de griferías con el premio iF...
Mehr lesen
RIR de Ramon Soler®, ahora en los acabados de moda
Un rociador de pared redondo, efecto lluvia, disponible...
Mehr lesen
El acabado más sofisticado en una grifería de elegancia
Columna monomando para lavabo negro mate de la colección Alexia...
Mehr lesen
Ramon Soler® se convierte en #BREEAMER
Ramon Soler® obtiene el certificado BREEAM® que aportar valor...
Mehr lesen
RIK de Ramon Soler®, con forma geométrica
Para los amantes de la geometría y el minimalismo, un rociador...
Mehr lesen
El rociador con salida en cascada más minimalista
El rociador empotrado a pared RCE02 aúna el diseño...
Mehr lesen
Grifo de cocina con caño alto giratorio de Ramon Soler®
La grifería de cocina más minimalista en los últimos...
Mehr lesen
Grifería de ducha Termotech de Ramon Soler®
La democracia del diseño en una grifería termostática...
Mehr lesen
Níquel cepillado para las griferías más sofisticadas
Últimas tendencias globales en diseño...
Mehr lesen
Cromoterapia en tu baño con Ramon Soler®
Rociador circular de techo con cromoterapia RELED570...
Mehr lesen
Ramon Soler® lanza el nuevo Catálogo-Tarifa 2021
Nuevo catálogo con las últimas novedades que entra...
Mehr lesen
Grifo de cocina 3829 de acero inoxidable de Ramon Soler®
Un grifo de cocina de líneas refinadas, el perfecto...
Mehr lesen
Un baño entre el Cielo y la Tierra
El oro cepillado de la colección Alexia de Ramon Soler®...
Mehr lesen
Ducha higiénica WC Magnet de Ramon Soler®
La revolucionaria ducha para la higiene personal al lado...
Mehr lesen
Magnet Kitchen premio iF DESIGN AWARD 2021
Ramon Soler® ha sido galardonado por segundo año consecutivo...
Mehr lesen
Los monomandos con apertura en frío los más ecosostenibles
La firma vela por el uso responsable del agua y la energía...
Mehr lesen
Sostenibilidad y tendencia de la mano de Ramon Soler®
El ahorro de agua y un buen diseño no están reñidos...
Mehr lesen
Ramon Soler® apoya al deporte femenino
La firma se convierte en patrocinador del equipo...
Mehr lesen
Un baño que te enamorará
Equipado con la vanguardista colección Alexia negro mate de Ramon Soler®...
Mehr lesen
El ÁNODO DE SACRIFICIO de Ramon Soler®
La última patente de Ramon Soler®, triplica la protección...
Mehr lesen
Ramon Soler® se colabora en la gran recogida de alimentos
Una campaña que tendrá lugar del 30 de noviembre al...
Mehr lesen
“Se lleva el Oro” de Ramon Soler®
La sofisticación del acabado oro cepillado en las colecciones...
Mehr lesen
Conjunto de ducha empotrado y termostático, negro mate
Diseño, innovación y tendencias en el nuevo conjunto...
Mehr lesen
Ramon Soler® se suma a la revolución del BIM
Modelando gran parte de sus productos en formato BIM...
Mehr lesen
Llenamos todas las mochilas para ir al colegio
Ramon Soler® inicia una nueva campaña de recogida...
Mehr lesen
Nuevo grifo de cocina con acabado cobre
Marcar tendencia en la cocina es posible con este grifo...
Mehr lesen
Ramon Soler® protege la seguridad y salud de todos
Ramon Soler® realiza pruebas médicas de serología...
Mehr lesen
Ramon Soler® certificado por EcoVadis
Ramon Soler® obtiene la medalla de bronce 2020 como...
Mehr lesen
Solestop Quick Set-Up de Ramon Soler®
“La grifería temporizada con la que reducir el tiempo de...
Mehr lesen
Ducha cascada para exterior de Ramon Soler®
Rociador RCEXT extraplano y de acero inoxidable...
Mehr lesen
KIT BLAUTHERM monomando empotrado de Ramon Soler®
La firma demuestra una vez más su constante preocupación...
Mehr lesen
Ramon Soler® ayuda contra el Covid-19
La firma colabora en la lucha contra el Covid-19 donando griferías...
Mehr lesen
Ramon Soler® imparte WEBINARS a profesionales
En ellos se habla sobre diferentes soluciones, consejos y...
Mehr lesen
Rociador de techo con cromoterapia
Disfrutamos del agua a todo color para estimular nuestros sentidos...
Mehr lesen
Grifería electrónica Soltronic 8102 de Ramon Soler®
La grifería clave para ayudar a combatir la emergencia...
Mehr lesen
La grifería más sanitaria de Ramon Soler®
Tecnología y accesibilidad al alcance de todos...
Mehr lesen
Ramon Soler® lanza su nuevo Catálogo 2020
Para celebrar su 130 aniversario Ramon Soler® presenta...
Mehr lesen
Celebra la Convención Nacional de Ventas 2020
Una convención muy especial, ya que este año la firma...
Mehr lesen
Elegancia y tecnología a tu alcance
Columna de ducha termostática Blautherm negro mate...
Mehr lesen
Ramon Soler® celebra sus 130 años en CEVISAMA 2020
NIVEL 2 PABELLÓN 6 STAND B125 | Del 3 al 7 de febrero...
Mehr lesen
Nuevo grifo de cocina extraíble con sistema de imanes
Un grifo de cocina de estética industrial y vanguardista...
Mehr lesen
3 de 20
Mostrar más
Adagietto de ramonsoler®
Adagio expresa su aire más minimalista y simétrico con su versión Adagietto.
Adagietto de ramonsoler®
Adagio expresa su aire más minimalista y simétrico con su versión Adagietto.
Adagietto de ramonsoler®
Adagio expresa su aire más minimalista y simétrico con su versión Adagietto.
3 de 20
Mostrar más
